Bez PoE sady
Tento model AP je urcen pro instalace, kde lze ocekávat velký pocet pripojených klientu (PC, notebook, tablet, mob.telefon)
Dimensions 220 x 220 x 48.1 mm (8.66 x 8.66 x 1.89")
Weight
With Mounting Kits 700 g (1.54 lb)
830 g (1.83 lb)
Networking Interface (2) 10/100/1000 Ethernet Ports
Buttons Reset
Power Method Passive Power over Ethernet (48V), 802.3at PoE+ Supported
Supported Voltage Range 44 to 57VDC
Power Supply 48V, 0.5A PoE Gigabit Adapter*
Power Save Supported
Maximum Power Consumption 17W
TX Power
2.4 GHz 6-25 dBm
5 GHz 6-25 dBm
Antennas
2.4 GHz
5 GHz (2) Dual Port, Dual Polarity Antennas, 3 dBi each
(2) Dual Port, Dual Polarity Antennas, 4 dBi each
Wi-Fi Standards 802.11 a/b/g/n/ac/ac-wave2
Wireless Security WEP, WPA PSK, WPA Enterprise (WPA/WPA2, TKIP/AES)
BSSID Up to Four per Radio
Mounting Wall/Ceiling (Kits Included)
Operating Temperature 10 to 70° C (14 to 158° F)
Operating Humidity 5 to 95% Noncondensing
Certifcations CE, FCC, IC
* Only the single-pack of the UAP-AC-HD includes a PoE adapter.
Advanced Traffc Management
VLAN 802.1Q
Advanced QoS Per-User Rate Limiting
Guest Traffc Isolation Supported
WMM Voice, Video, Best Effort, and Background
Concurrent Clients 500+
Kód produktu | AX49416 |
---|---|
MPN kód | UAP-AC-HD-5 |
Značka | Ubiquiti Networks |
Záruka | 24 měsíců |
