GIGABYTE (H410M H V2)

Chipset: Intel® H470

Rozmerový formát: Micro ATX Form Factor (226 mm x 185 mm)
Podpora pro procesory: Support for 10th Generation Intel® Core™ i9 processors/Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1200 package
Patice procesoru: LGA 1200

Pozice na pameti: 2x DDR4 DIMM
Podpora pro pameti:
*Intel® Core™ i9/i7 processors: DDR4 2933/2666/2400/2133 MHz memory modules
*Intel® Core™ i5/i3/Pentium®/Celeron® processors: DDR4 2666/2400/2133 MHz memory modules
Max.velikost operacní pameti: 64 GB
Podpora pro pameti typu: DDR4
*Dual channel memory architecture
*ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
*non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
*Extreme Memory Profile (XMP) memory modules

Grafická karta:
*Integrated Graphics Processor (na základe procesoru)

Zvuková karta:
*Realtek® Audio CODEC

Sítová karta:
*Intel® GbE LAN chip (1 Gbit/100 Mbit)

Rozširující sloty:
*1x PCI Express x16 slot, running at x16
*2x PCI Express x1 slots

RAID radic: 0, 1, 5, a 10

SATA:
*4x SATA 6Gb/s

M.2:
*1x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support)

USB:
*zadní USB porty ( celkem 6 )
*2x USB 3.2 Gen 1 ports
*4x USB 2.0/1.1 ports
*prední USB porty ( celkem 4 )
*2x USB 3.2 Gen 1 ports
*2x USB 2.0/1.1 ports

Interní porty:
*1x 24-pin ATX main power connector
*1x 8-pin ATX 12V power connector
*1x CPU fan header
*1x system fan header
*1x RGB LED strip header
*4x SATA 6Gb/s connectors
*1x front panel header
*1x front panel audio header
*1x USB 3.2 Gen 1 header
*1x USB 2.0/1.1 header
*1x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
*1x serial port header
*1x Clear CMOS jumper

Externí porty:
*1x PS/2 keyboard/mouse port
*1x D-Sub port
*1x HDMI port
*2x USB 3.2 Gen 1 ports
*4x USB 2.0/1.1 ports
*1x RJ-45 port
*3x audio jacks

BIOS: 1 x 256 Mbit flash, Use of licensed AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Stránka výrobce: https://www.gigabyte.com/Motherboard/H410M-H-V2-rev-10
