ATEN 2-port DVI KVMP (CS-1642A)

CS1642
ATEN 2-port DVI KVMP DVI USB, 2port USB HUB, audio, 1.2m kabely

Produkt je certifikován jako kompatibilní s technologií 3D Vision Ready od spolecnosti nVidia pro kvalitní a plynulý herní zážitek ve 3D.

- maximální rozlišení až 2560x1600@60Hz rozlišení DVI Dual Link
- maximální rozlišení pro 3D až 1920x1200@120Hz rozlišení DVI Single Link
- zobrazení na dvou monitorech Dual View
- podpora DVI Digital i Analog, HDCP kompatibilní
- podpora širokouhlých rozlišení
- video DynaSync - uchová EDID monitoru konzole pro optimální rozlišení
- umožnuje spravovat 2 PC na jedné kl.,m.,monitoru a dve dalši USB zarízení
- možnost pripojit pocítace po USB
- možnost nezávislého prepínání KVM, USB a audia
- vcetne kabelu pro propojení PC-prepínac
- umožnuje pripojit PC Windows, Mac, Linux, Sun, FreeBSD
- OSD, hotkey switch, port pro upgrade firmware
- audio 2.1 surround
- vcetne kabelu, v sade
- USB 2.0 vcetne 2 port USB2.0 HUBu pro pripojení dalších periferií
- umožnuje i prepínání audia

konektory:

vstup pro pocítace:
DVI
USB A

vstup pro konzole:
DVI
USB A
+ 2x port USB pro další periferie

tyto konektory najdete na priložených propojovacích
kabelech

Podpora Windows 7.
[ENG]
CS1642A
2-Port USB DVI Dual View KVMP™ Switch

The CS1642A/CS1644A 2/4-Port USB DVI Dual View KVMP™ Switch is a multi-application device that integrates a 2/4-port KVM switch
with 2-port USB hub. The newest version now supports Quad-View functionality with two Dual View KVM Switches connected.

The new CS1642A/CS1644A features multi-view capabilities, which allow two switches to be daisy chained for a dual, triple, or quadview
display across multi-monitor installations. The CS1642A/CS1644A supports advanced nVidia 3D Vision ready 120Hz 3D displaying,
allowing you to manage various 3D visual effects. It allows you to manipulate all connected computers from a single console to
save resources and work space. It enables each computer to access connected peripherals on a one-computer-at-a-time basis, making
it ideal for users who need delicate visual effects and multi-tasking on several computers. The CS1642A/CS1644A is perfect for graphic
designers, banking and financial consultants, gamers and medical professionals- demanding a high quality switch that provides stunning
color, clarity and functionality.

One dual-screen USB console controls two/four dual-screen
computers and two additional USB devices
• Multi-View Display – Easily connect two CS1642A/1644A's units for a second dual-screen setup controlled through a single connection
• Superior video quality – 2650x1600 at 60Hz (DVI Dual link); and 3D displays up to 1920x1200 at 120Hz (DVI Single link)
• Supports widescreen resolutions
• Independent switching of KVM, USB, and Audio focus
• DVI digital and analog monitor support – fully compliant with DVI specifi cations; and HDCP compliant
• Multiplatform support – Windows 2000/XP/Vista, Linux*, Mac, Sun, and FreeBSD
• Sun/Mac keyboard support and emulation**
• Video DynaSync, exclusive ATEN technology, to eliminate boot-up display problems and optimizes resolution when switching between ports

* Supports Linux Kernel 2.6 and higher. The CS1642A/CS1642A has a builtin USB 2.0 hub, so will not support PCs or OS that do not support USB 2.0.
** PC keyboard combinations emulate Mac keyboards.
** Mac keyboards only work with their own compute
